FileNet Configuration Manager setting issue

http://webcache.googleusercontent.com/search?q=cache:_PCYKHiUYDAJ:ecmplace.com/viewtopic.php%3Ff%3D102%26t%3D16307+&cd=3&hl=es-419&ct=clnk&gl=mx

 FileNet Configuration Manager setting issue
I am trying to configure FileNet 5 CE on WAS 7.0.0.13 on Windows 2008 R2 machine
Websphere security is configured for Standalone LDAP server ( Active directory ).
When I go to Application Server cell dropdown in the Profile section of FileNet Configuration Manager , I get the following error ( shown at the top ) -
com.ibm.ecm.configmgr.engine.ConfigurationManagerException: An error occurred while retrieving information from server:

When I manually enter the cell name in the Application Server cell dropdown box and click on Test Connection , I get the following error in the logs -

com.ibm.ecm.configmgr.engine.ConfigurationManagerException: An error occurred while retrieving the cell name information.
WebSphere:process=server1,type=ConfigService,*

at com.ibm.ecm.configmgr.engine.jmx.JMXInvoker.invokeConnectMethodAndMethods(JMXInvoker.java:218)

at com.ibm.ecm.configmgr.engine.jmx.JMXInvoker.invokeConnectMethodAndMethod(JMXInvoker.java:122)

at com.ibm.ecm.configmgr.engine.jmx.WebSphereJMXInvoker.connect(WebSphereJMXInvoker.java:83)

at com.ibm.ecm.configmgr.app.ce.applicationserver.WebsphereApplicationServer$TestActivity.testWork(WebsphereApplicationServer.java:338)

at com.ibm.ecm.configmgr.engine.profile.EnvironmentTestActivity.test(EnvironmentTestActivity.java:64)

at com.ibm.ecm.configmgr.ui.wizards.NewProfileWizardPageGetProfileEnvironmentProps$3.widgetSelected(NewProfileWizardPageGetProfileEnvironmentProps.java:445)

at org.eclipse.swt.widgets.TypedListener.handleEvent(TypedListener.java:228)

at org.eclipse.swt.widgets.EventTable.sendEvent(EventTable.java:84)

at org.eclipse.swt.widgets.Widget.sendEvent(Widget.java:1003)

at org.eclipse.swt.widgets.Display.runDeferredEvents(Display.java:3910)

at org.eclipse.swt.widgets.Display.readAndDispatch(Display.java:3503)

at org.eclipse.jface.window.Window.runEventLoop(Window.java:825)

at org.eclipse.jface.window.Window.open(Window.java:801)

at com.ibm.ecm.configmgr.app.ce.handlers.EditAppServerPropsHandler.execute(EditAppServerPropsHandler.java:45)

at org.eclipse.ui.internal.handlers.HandlerProxy.execute(HandlerProxy.java:294)

at org.eclipse.core.commands.Command.executeWithChecks(Command.java:476)

at org.eclipse.core.commands.ParameterizedCommand.executeWithChecks(ParameterizedCommand.java:508)

at org.eclipse.ui.internal.handlers.HandlerService.executeCommand(HandlerService.java:169)

at org.eclipse.ui.internal.handlers.SlaveHandlerService.executeCommand(SlaveHandlerService.java:241)

at org.eclipse.ui.internal.handlers.SlaveHandlerService.executeCommand(SlaveHandlerService.java:241)

at org.eclipse.ui.menus.CommandContributionItem.handleWidgetSelection(CommandContributionItem.java:770)

at org.eclipse.ui.menus.CommandContributionItem.access$10(CommandContributionItem.java:756)

at org.eclipse.ui.menus.CommandContributionItem$5.handleEvent(CommandContributionItem.java:746)

at org.eclipse.swt.widgets.EventTable.sendEvent(EventTable.java:84)

at org.eclipse.swt.widgets.Widget.sendEvent(Widget.java:1003)

at org.eclipse.swt.widgets.Display.runDeferredEvents(Display.java:3910)

at org.eclipse.swt.widgets.Display.readAndDispatch(Display.java:3503)

at org.eclipse.ui.internal.Workbench.runEventLoop(Workbench.java:2405)

at org.eclipse.ui.internal.Workbench.runUI(Workbench.java:2369)

at org.eclipse.ui.internal.Workbench.access$4(Workbench.java:2221)

at org.eclipse.ui.internal.Workbench$5.run(Workbench.java:500)

at org.eclipse.core.databinding.observable.Realm.runWithDefault(Realm.java:332)

at org.eclipse.ui.internal.Workbench.createAndRunWorkbench(Workbench.java:493)

at org.eclipse.ui.PlatformUI.createAndRunWorkbench(PlatformUI.java:149)

at com.ibm.ecm.configmgr.app.ce.rcp.Application.start(Application.java:85)

at org.eclipse.equinox.internal.app.EclipseAppHandle.run(EclipseAppHandle.java:194)

at org.eclipse.core.runtime.internal.adaptor.EclipseAppLauncher.runApplication(EclipseAppLauncher.java:110)

at org.eclipse.core.runtime.internal.adaptor.EclipseAppLauncher.start(EclipseAppLauncher.java:79)

at org.eclipse.core.runtime.adaptor.EclipseStarter.run(EclipseStarter.java:368)

at org.eclipse.core.runtime.adaptor.EclipseStarter.run(EclipseStarter.java:179)

at sun.reflect.NativeMethodAccessorImpl.invoke0(Native Method)

at sun.reflect.NativeMethodAccessorImpl.invoke(NativeMethodAccessorImpl.java:48)

at sun.reflect.DelegatingMethodAccessorImpl.invoke(DelegatingMethodAccessorImpl.java:37)

at java.lang.reflect.Method.invoke(Method.java:600)

at org.eclipse.equinox.launcher.Main.invokeFramework(Main.java:559)

at org.eclipse.equinox.launcher.Main.basicRun(Main.java:514)

at org.eclipse.equinox.launcher.Main.run(Main.java:1311)

Caused by: javax.management.InstanceNotFoundException: WebSphere:process=server1,type=ConfigService,*

at com.ibm.websphere.management.configservice.ConfigServiceProxy.<init>(ConfigServiceProxy.java:67)

at com.ibm.ecm.configmgr.utils.websphere.WebSphereJMXUtil.getCells(WebSphereJMXUtil.java:298)

at sun.reflect.NativeMethodAccessorImpl.invoke0(Native Method)

at sun.reflect.NativeMethodAccessorImpl.invoke(NativeMethodAccessorImpl.java:48)

at sun.reflect.DelegatingMethodAccessorImpl.invoke(DelegatingMethodAccessorImpl.java:37)

at java.lang.reflect.Method.invoke(Method.java:600)

at com.ibm.ecm.configmgr.engine.jmx.JMXInvoker.invokeConnectMethodAndMethods(JMXInvoker.java:178)

... 46 more



Any idea on how to proceed or things to look out for ?

Thanks,
Amit

Thu Jun 16, 2011 7:32 amProfile Send private message E-mail

ECMPlace User
ECMPlace User

Joined: Thu Jun 16, 2011 7:19 am
Posts: 11
Post Re: FileNet Configuration Manager setting issue
I was finally able to get past this error by reinstalling WAS 7.0.0.13 (ND). Currently, test connection works with dmgr SOAP port (8879) but it doesn't for the appserver port(same config service error). I am using the dmgr port for further deployment (not sure if it is correct). All my datasource tests are successful.
When I try to deploy the application using the Configuration Manager, I get the following error:

Starting to run Deploy Application

Deploy Application **********************
Finished running Deploy Application
An error occurred while running Deploy Application
Running the task failed with the following message: The application deployment failed.
WASX7209I: Connected to process "dmgr" on node WINADV95CellManager01 using SOAP connector; The type of process is: DeploymentManager
Turn off RMI/IIOP SSL
configure server transaction time out
ADMA5016I: Installation of FileNetEngine started.
ADMA5026E: No valid target is specified in ObjectName WebSphere:cell=WINADV95Cell01,node=WINADV95CellManager01,server=server1 for module acce.war+WEB-INF/web.xml.
ADMA5011I: The cleanup of the temp directory for application FileNetEngine is complete.
ADMA5014E: The installation of application FileNetEngine failed.
WASX7017E: Exception received while running file "C:\AMSAPPS\FileNetCE\tools\configure\tmp/deployapplication.tcl"; exception information: com.ibm.ws.scripting.ScriptingException: WASX7132E: Application install for C:\AMSAPPS\FileNetCE\tools\configure\profiles\AdvantageProfile\ear\Engine-ws.ear failed: see previous messages for details.


Even though , I select the node as WINADV95Node01 ( in the graphical interface ) , I am not sure why it is taking it as WINADV95CellManager01.

Any idea about this.

Thanks,
Amit


Attachments:
FileNet_CM_Screenshot.jpg [ 138.55 KiB | Viewed 1187 times ]
File comment: Cell Topology
Cell_topology.jpg [ 51.9 KiB | Viewed 1187 times ]
Mon Jun 20, 2011 4:11 amProfile Send private message E-mail

Moderator
Moderator
User avatar

Joined: Fri Oct 08, 2004 9:47 am
Posts: 2228
Location: United Kingdom
Post Re: FileNet Configuration Manager setting issue
Before tackling the issue you describe, I noticed that your on WAS 7.0.0.0 - but the SW requires at a minimum WAS 7.0.0.9

Page 12: https://www-304.ibm.com/support/docview ... aid=7&wv=1

_________________
Kind Regards
Robert Brauer
ECMPlace - Site Administrator
"The driving force behind a good implementation is a brilliant implementation team ... are you part of that team?"

Mon Jun 20, 2011 8:28 amProfile Send private message E-mail WWW

ECMPlace User
ECMPlace User

Joined: Thu Jun 16, 2011 7:19 am
Posts: 11
Post Re: FileNet Configuration Manager setting issue
Actually, we are using WAS 7.0.0.13 ( as described in my earlier post).

I was able to get past the error.
Steps followed were as follows -
1. Used the dmgr SOAP port in the application server properties.
2. For ND based WAS , it seems it needs cluster based environment. So, I created a cluster based environment and added server1 under it.
3. The Deployment type selected under deployment task was Cluster based and my deployment ran successfully. I was able to deploy the FileNet CE in server1 present under a cluster.
Am in the process of configuring the Enterprise Manager.

We are looking for uploading/downloading attachments in FileNet through webservices provided by FileNet from our application(Java based ). We also need to be able to search for the documents uploaded in FileNet. This is the only requirement . Do we need to install FileNet Process Engine.
Are there any good links to refer to for using Java WebServices in FileNet.

Thanks,
Amit

Mon Jun 20, 2011 5:00 pmProfile Send private message E-mail

ECMPlace User
ECMPlace User

Joined: Thu Jun 16, 2011 7:19 am
Posts: 11
Post Re: FileNet Configuration Manager setting issue
My bad. During my reinstall of WAS, I had missed out to install the FixPack and so , my latest WAS version was 7.0.0.0
Thanks for pointing it out.

Regards,
Amit

Mon Jun 20, 2011 5:21 pmProfile Send private message E-mail

Moderator
Moderator
User avatar

Joined: Fri Oct 08, 2004 9:47 am
Posts: 2228
Location: United Kingdom
Post Re: FileNet Configuration Manager setting issue
amitu wrote:
Actually, we are using WAS 7.0.0.13 ( as described in my earlier post).
We are looking for uploading/downloading attachments in FileNet through webservices provided by FileNet from our application(Java based ). We also need to be able to search for the documents uploaded in FileNet. This is the only requirement . Do we need to install FileNet Process Engine.
Are there any good links to refer to for using Java WebServices in FileNet.

Thanks,
Amit


If your not planning on doing any Process related activities, there is no need to install the Process Engine.

https://www-304.ibm.com/support/docview ... SNVNV&wv=1

Go look there, under the heading FileNet Developer Samples ... some stuff there might be of use to you

_________________
Kind Regards
Robert Brauer
ECMPlace - Site Administrator
"The driving force behind a good implementation is a brilliant implementation team ... are you part of that team?"
